Description

POSITIVE POWER TOLERANCE
0~+5W

MAXIMUM POWER OUTPUT POSITIVE POWER TOLERANCE
405W

MAXIMUM EFFICIENCY
21.1%

PRODUCT RANGE: 380-405W

High value

• More productivity from the same roof size.
• Outstanding visual appearance.
• Leading 210mm cell technology.

Small in size, big on power

• Small format modules allow greater energy generation in limited space.
• Up to 405W, 21.1% module efficiency with high density interconnect technology.
• Multi-busbar technology for better light trapping effect, lower series resistance, and improved current.
• Reduce installation costs with higher power bins and efficiency.
• Boost performance in warm weather with a lower temperature coefficient (-0.34%) and operating temperature.

Universal solution for residential and C&I rooftops

• Designed for compatibility with existing mainstream optimizers, inverters, and mounting systems.
• Perfect size and low weight make handling and transportation easier
and more cost-eective.
• Diverse installation solutions for flexibility in system deployment

High Reliability

• 25-year product warranty.
• 25-year performance warranty with the lowest degradation.
• Minimized micro-cracks with innovative non-destructive cutting
technology.
• Ensured PID resistance through cell process and module material
control.
• Mechanical performance up to +6000 Pa and-4000 Pa negative load



WARRANTY

25-year Product Workmanship Warranty 25-year Power Warranty

2% first year degradation

0.55% Annual Power Attenuation



TEMPERATURE RATING



NOCT(Nominal Operating Cell Temperature) 43°C (±2°C)

Temperature Coefficient of PMAX 0.34%/°C

Temperature Coefficient of VOC – 0.25%/°C
Temperature Coefficient of ISC 0.04%/°C



MAXIMUM RATINGS



Operational Temperature -40~+85ºC

Maximum System Voltage 1500V DC (IEC)

1500V DC (UL)

Max Series Fuse Rating 25A

PACKAGING CONFIGURATION

Modules per box: 36 pieces
Modules per 40’ container: 828 pieces
